Camera

Image Sensor:8.29 MP high performance CMOS

Effective Pixels:3840 (H) × 2160 (V)

Shutter Time:PAL: 1/12.5 s to 1/10,000 s

NTSC: 1/15 s to 1/10,000 s

Lens Mount:M12

Adjustment Range:Pan: 0° to 360°, Tilt: 0° to 75°, Rotate: 0° to 360°

Day& Night:IR cut filter with auto switch

Video Frame Rate:PAL: 8 MP@12.5fps, 5 MP@20fps, 4 MP@25fps, 1080p@25fps

NTSC:8 MP@15fps, 5 MP@20fps, 4 MP@30fps, 1080p@30fps

HD Video Output:1 Analog HD output

Synchronization:Internal Synchronization

Menu

D/N Mode:Auto / Color / B/W

Auto White Balance:Auto/Manual/Natural

BLC:Support

Language:English

General

Operating Conditions:-40 °C – 60 °C (-40 °F – 140 °F)

Humidity 90% or less (non-condensing)

Power Supply:12 VDC ±25% *You are recommended to use one power adapter to supply the power for one camera.

Weather Proof:IP67

IR Range:Up to 60m

Communication :Up the coax

Protocol:HIKVISION-C(Coaxitron)

Dimension:? 109.8 mm × 96.3 mm (? 4.32″ × 3.79″ )

Weight:Approx. 360 g (0.79 lb.)
